Dimmers

3Way Slide Dimmer

Category:
Residential, DIMMER, Wiring Devices
SKU:
BAK-004AG
{{variant.name}}:
{{opt.name}}
{{opt.value ? '' : opt.name}}
{{opt.value ? '' : opt.name}}
Description

3Way Slide Dimmer



  • Model No.: BAK-004AG
  • About 60 Gr
  • UI-1472 Solid Dimmer Switch
  • Rated working Power: 600W
  • Rated working voltage: 120V 60Hz
  • Insulation Resistance: >10MΩ (DC500V)
  • Withstand Voltage: 1500 (AC)
  • Mechanical Life: 40,000 times (one reciprocating time for each switch)
  • Rubber shell fire rating: UL94-V2
  • Creepage distance: ≥3mm
  • Electrical clearance: 1.2mm between live parts & 3mm
  • between live parts & other parts
  • Cable Specification: 18AWG
  • Working Temperature: -20°C~60°C
  • Option : Class A ( compatible with most lights)
